Pride Victory 10 3
Wheel Scooter
 |
FDA
Class II Medical Device
If we at
Pride could only recommend one scooter for most buyers, it
would be the Victory 10 Scooter. This mid-size scooter
packs a punch with many standard features, such as the
ambient voltmeter that adjusts brightness automatically in
low-light settings, enabling you to check your battery life.
Equipped with a large front basket, the Victory 10 Scooter
makes it much easier for you to carry your bags while
shopping. An integrated cup holder carries your beverage and
a convenient hideaway storage area on the tiller houses your
keys and wallet, plus many other features are included!
|
|
As mid-size scooters go, the Victory 10 mobility scooter
gets everything right. The 18”x17” swivel seat with sliders
for added comfort allows you to get on and off the scooter
with ease. A roomy foot deck allows you to stretch out and
feel comfort as you experience a smooth ride over many types
of terrain. With a reliable performance and an excellent
per-charge range of up to 13 miles, you can go a little
farther, a little longer throughout the day. |
|
 |
Victory® 10 3-Wheel Features:
400 lbs. weight capacity.
5.2 mph maximum speed.
42" turning radius.
(U1) 11 miles per charge.
(40AH) 13.5 miles per charge.
Standard front basket.
|
|
Puddle light / Head light.
Integrated storage/cup holder in tiller.
Ambient Battery indicator adjusts brightness.
Integrated USB mobile device charging port in tiller.
New frosted LED headlights and low-mounted LED pathway light
brightens your route.
Delta tiller with wraparound handles.
Pinchless hinge seat with swivel and sliders for increased
comfort. Available in sizes 18” x 17” and 20” x 18”.
Exclusive stylish, non-scuffing, black, low-profile tires.
Easy-grip tiller adjustment knob.
Easy access tiller-mounted charger port. |
 |
| |
|
|
|
Our standard suite of features such as frosted LED
headlights combine with a low-mounted LED pathway light to
brighten your route, no matter where you go. An under tiller
puddle light not only lights up the scooter deck for
transferring on and off your scooter but also enables you to
plug your mobile device into the built-in USB charger port! . |
|
Model |
Victory 10, 3 wheel |
Victory 10, 4 wheel |
|
Model Number |
SC610 |
SC710 |
|
Front Tires |
3.5" x 10" Solid |
3.5" x 10" Solid |
|
Rear Tires |
3.5" x 10" Solid |
3.5" x 10" Solid |
|
Maximum Speed* |
Up to 5.25 MPH |
Up to 5.25 MPH |
|
Ground Clearance |
3" at mid frame |
3" at mid frame |
|
Turning Radius** |
42" |
54" |
|
Overall Length** |
45.25" |
47" |
|
Overall Width of Base** |
22.25" |
22.25" |
|
Seat-to-Ground Height Range |
20.5"-22" |
20.5"-22" |
|
Seat Type |
Foldable, Molded Plastic (18"x17") |
Foldable, Molded Plastic (18"x17") |
|
Weight** |
133.5 lbs. |
137.5 lbs. |
|
Seat-to-Deck Height Range |
17.5-19" |
17.5-19" |
|
Battery Weight |
24.5 lbs. each/32.5 lbs. each |
24.5 lbs. each/32.5 lbs each |
|
Battery Requirements |
(2)U1 or (2)40AH |
(2)U1 or (2)40AH |
|
Maximum Range Per Charge* |
Up to 15.5 miles |
Up to 15.5 miles |
|
Battery Charger |
Off-board, 3.5A (U-1)/
Off-board, 5A (40 AH) |
Off-board, 3.5A (U-1)/
Off-board, 5A (40 AH) |
|
Maximum Weight Capacity |
400 lbs. |
400 lbs. |
|
Standard Body Colors |
Candy Apple Red, Viper Blue |
Candy Apple Red, Viper Blue |
|
Weight of Heaviest Piece** |
54.5 lbs. (Front Section) |
61 lbs. (Front Section) |
|
Warranty |
Lifetime limited on frame;
2-Year limited on Electronics;
2-Year limited on Drivetrain |
Lifetime limited on frame;
2-Year limited on Electronics;
2-Year limited on Drivetrain |
|
Owners Manual |
Manual |
|
|
Promotional Sheet |
Victory_10 3 Wheel Promo |
|
Meeting and Exceeding High Standards for your Peace of Mind.
Pride FDA Class II Medical Devices are designed to aid
individuals with mobility impairments.
Your Pride product has undergone thorough product testing to
ensure safety, durability and performance.
Our power chairs, scooters and lift chairs are Food & Drug
Administration (FDA) approved medical products that require
specific testing prior to release for public use.
The testing requirements accepted by the FDA were developed by
the American National Standards Institute/Rehabilitation
Engineering & Assistive Technology Society of North America
(ANSI/RESNA).
The tests are conducted in accordance with the requirements of
the ANSI/RESNA Test Standards and complement an additional
stringent testing regiment developed by Pride's Research &
Development Team.
All products have passed, and in many cases, exceeded test
criteria set forth, assuring the high level of quality
synonymous with Pride.
Some of the items our testing criteria include are:
- Product Stability & Brakes
Effectiveness Tests
- Fatigue & Impact Strength
Verification Tests
- Overall Product
Performance Verification
- Dimensional Requirement
Compliance
- Product Durability &
Reliability Testing
- Material Protective
Coating Testing Verification
- Misuse and Abuse Testing
- Ergonomic Verification
- Environmental Testing for
Adverse Weather Operation Conditions
- Electronic Systems
Performance and Durability
- Chemical and
Bio-Contamination Analysis Testing for Toxicity Verification
- Cal 117 Flammability Test
Compliance for Seating Foam and Fabric Components
- UL94VO Flammability
Testing for Compliance of Plastic Components
- Electromagnetic
Compatibility (EMC)
 |
 |
| Viper
Blue |
Candy
Apple Red |
|
Pride Victory 10 3 Wheel Mobility Scooter |
|
|
|
