Porch Lift
 |
Porch Lift Americas Favorite Wheelchair Lift with a
850
pound capacity and the ability to lift up to 50, 60
or 72
inches all will give you your freedom
providing access to the world as well as to areas
you were never able to gain access to before.
The P-Lift-50 is one of
the quietest products available when installed and
adjusted to factory specifications.
By utilizing an screw design the P-Lift-50
wheelchair lift is inherently safe and you are not
exposed to the safety issues that chain driven lift
are exposed to.
Residential porch lifts
are a simple, affordable solution for creating easy
home access. Even a few steps can be a large barrier
to someone with limited mobility. A P-Lift-50
Residential Wheelchair Lift is designed for indoor
or outdoor use to provide a safer home environment
and a better quality of life.
|
| The
P-Lift-50 porch platform lift is equipped with a keyed ignition lockout
so individuals & children can not use the lift when
you do not want them using it.
The P-Lift-50 also has a
emergency stop button and a second keyed locking
panel for access to controls.
The P-Lift-50 porch
wheelchair lift is the
only porch lift with three target buttons for up
as well as three target buttons for down, this gives
a disabled user a far greater range and ability to
operate the lift themselves without the need of a
aid or 2nd individual to activate the lift. |
 |
 |
The 90 Degree platform
option (Shown To The Left) Allows users to turn left
or right to exit once they enter the lift. The
standard orientation is a straight through. Meaning
you enter from one side and go straight through
exiting the opposite side once lifted. |
The
P-Lift-72 porch platform lift option allows users to travel a full 72"
or 6' (six feet)
The 72 option is also reversible allowing the tower
to be placed on either side and as with the 50 or 60
model the 72 has a upper limit switch that once
adjusted will stop the lift perfectly where you need
it automatically every time. |
 |
| |
|
| |
|
Specifications
Constant Pressure Operation – for safety
Up to 850lb weight capacity
8 ft/min travel speed
Total Travel: 50in
Synchronous Geared Belt Drive with Brake
Screw Design
Durable Powder Coated Steel Construction
1 x 110 VAC Single Phase, 15A power required
Platform Size: 34in (Wide) x 54in (Long) |
|
| |
|
|
Lifting Capacity |
850
lb |
|
Standard Lift Height |
50" |
|
Drive System |
Screw Drive |
|
Constant Pressure Platform Control |
Yes |
|
Emergency Stop Platform Control |
Included |
|
Platform Type |
Solid with Non-Skid Coating |
|
Straight Through
Platform Size |
34" x 54" |
|
Straight Through
Lift Footprint |
48"
x 54" |
|
90 Degree Access
Platform Size |
40" x 54" |
|
90 Degree Access
Lift Footprint |
54" x 54" |
|
Platform Configuration |
Straight-Thru Access |
|
Optional Platform Configurations |
Same Side Entry-Exit |
|
Grab Rail |
Included |
|
Maximum Stops |
2 |
|
Lift Speed (FPM) |
8 |
|
|
.
|
|
|
|
Porch Wheelchair Lift
P-Lift-50
porch platform lift was designed and engineered for home use.
It's easy to operate easy to install and
virtually maintenance free.  Every
safety detail has been carefully designed
into the
P-Lift-50 including
a non-slip platform, constant pressure
switches, a low platform for easy
roll-on/roll-off, safety barrier and
railing, and rolled edges.
The P-Lift-50 is a sturdy enough to lift and
lower up to 850 pounds and will accommodate
electric wheelchairs and scooters. Running
on a Threaded Screw rather then a gear box
and chain, the P-Lift-50 will provide a
smooth and quiet up and down ride, requiring
little maintenance. All mechanics are fully
enclosed, yet easy to access through the
rear or front of the housing unit. The
P-Lift-50 porch platform lift is completely weatherized and
attractively finished in extremely resilient
& durable Off White Color. |
|
|
Shipped fully assembled with the exception
of bolting on base, the P-Lift-50 install in
5 easy steps.
The P-Lift-50 Vertical Home Lift is the
economical and practical answer to stair
barriers. |
|
 |
-
The Vertical Home Lift P-Lift-50 have a
one year warranty on parts against defects
-
Powered with a 110 volt AC current, by a
�
HP motor
-
The toggle control switches with a
tamperproof key lock switch are on a low
voltage system, for safe operation
-
Power drive system is all weather(-30 -
l20 degrees)
-
Heavy duty worm drive gear box with heavy
duty Worm Gear (No dangerous
lifting chain)
-
36 inch high side guard rail
-
Hand crank for manual operation
-
Adjustable limit switches
-
Automatic access ramp and roll stop
-
Non slip platform
-
Capacity - 850 pounds
-
Standard lifting height 45 inches.
|
|
The Vertical Home Lift P-Lift-50 Uses a
screw rather than a lifting chain. Lifting
chains can be very unreliable where as a
driving screw delivers a smooth reliable
transfer from one level to the next. |
 |
|
|
The
P-Lift-50 porch platform lift
is one tough, safe, affordable lift.
|
|
 |
|
|
P-Lift-50 Porch Wheelchair Lift |
|
|
|
|
Americas
Favorite Porch Platform Lift
|
|
|
